Photo #1 shows the supplies we needed: 1/2" tubing to make the manifold, 1/2" figure-8 ends to seal off each end of the tubing, Miracle Punch, (3) tape x 1/4" barb fittings, roll of Aqua Traxx drip tape, (3) grip sleeve ends to seal off the far end of each drip tape line, and metal pins to hold the drip tape in place. Already attached to the bed (on the left) is a PVC riser and valve, and a 1/2" T compression fitting.
Photo #4: Attaching the tape x 1/4" barb fittings to the manifold. The next step (not shown) was installing the Aqua Traxx onto each barb fitting and tightening it to hold it in place.
|Photo #6: The finished product!|
